| MARCA |
MSI |
| MODELO |
PRO B650M-B |
| CHIPSET |
AMD B650 |
| TIPO DE SOCKET |
AM5 AMD |
| PROCESADORES |
AMD COMPATIBLE |
Procesador AMD Ryzen 9 SAM5 9XXX |
| Procesador AMD Ryzen 7 SAM5 9XXX |
| Procesador AMD Ryzen 5 SAM5 9XXX |
| Procesador AMD Ryzen 3 SAM5 9XXX |
| Procesador AMD Ryzen 3 SAM5 8XXX |
| Procesador AMD Ryzen 9 SAM5 8XXX |
| Procesador AMD Ryzen 7 SAM5 8XXX |
| Procesador AMD Ryzen 5 SAM5 8XXX |
| Procesador AMD Ryzen 9 SAM5 7XXX |
| Procesador AMD Ryzen 7 SAM5 7XXX |
| Procesador AMD Ryzen 5 SAM5 7XXX |
| MEMORIAS RAM |
COMPATIBLES |
Memoria RAM DDR5 8200 MHz PC5-65600 |
| Memoria RAM DDR5 7600 MHz
PC5-60800 |
| Memoria RAM DDR5 7200 MHz
PC5-57600 |
| Memoria RAM DDR5 6800 MHz
PC5-54400 |
| Memoria RAM DDR5 6400 MHz
PC5-51200 |
| Memoria RAM DDR5 6000 MHz
PC5-48000 |
| Memoria RAM DDR5 5600 MHz
PC5-44800 |
| Memoria RAM DDR5 5200 MHz
PC5-41600 |
| Memoria RAM DDR5 4800 MHz
PC5-38400 |
| NUMERO DE SOCKETS DIMM |
2 |
| EXPANSION MAXIMA EN GB |
96 |
| TECNOLOGIA |
AMD EXPO |
| Dual Channel |
| TIPO DE RAM |
DDR5 |
| VIDEO |
Revisar caracteristicas del Procesador |
| SONIDO |
TECNOLOGIA |
High Definition (HD) |
| CHIPSET |
Realtek ALC897 Codec |
| CANALES |
7.1 |
| CONECTIVIDAD |
ETHERNET |
CHIPSET |
Realtek
RTL8125BG |
| VELOCIDAD |
10
Mbps |
| 100 Mbps |
| 1000 Mbps |
| 2500 Mbps |
| ALMACENAMIENTO SERIAL
ATA |
NUMERO
DE PUERTOS |
4 |
| VELOCIDAD DE TRANSFERENCIA |
6 Gbit/s |
| RAID SATA |
RAID 10 |
| RAID 1 |
| RAID 0 |
| ALMACENAMIENTO M.2 |
NUMERO
TOTAL DE SLOTS M.2 KEY M |
1 |
| M.2 CPU |
1 x PCIe 4.0 x4 tipos |
2260 |
| 2280 |
| SLOTS DE EXPANSION |
PCI
Express CPU |
PCI
Express x16 slot, PCIe 4.0 modo x16 |
1 |
| PCI Express CHIPSET |
PCI
Express x1 slot, PCIe 3.0 |
1 |
| NOTA PCI Express CPU |
Velocidad varia con modelo del procesador |
| PUERTOS INTERNOS |
FRONT
PANEL AUDIO HEADER |
1 |
| USB 3.2 GEN 1 HEADER |
2 |
| USB 2.0 HEADER |
4 |
| PUERTOS BACK PANEL |
USB
3.2 GEN 1 TIPO-A |
4 |
| USB 2.0 TIPO-A |
2 |
| VGA |
1 |
| HDMI |
1 |
| RJ-45 |
1 |
| AUDIO JACKS |
3 |
| PS/2 KEYBOARD |
1 |
| PS/2 MOUSE |
1 |
| BIOS |
AMI BIOS UEFI |
| FACTOR DE FORMA Y
DIMENSIONES |
FACTOR
DE FORMA |
Micro-ATX |
| DIMENSIONES |
215 mm x 243.84 mm |
| PRESENTACION |
CAJA |
| CONECTORES FUENTE POWER |
1
x 24-pin ATX Main Power |
1 |
| 1 x 8-pin ATX 12V power |
1 |
